Metal Clad Enclosed High Voltage Switchgear
The rated voltage and frequency of KYN61-40.5 metal clad enclosed high voltage switchgear are 40.5KV, 50(60Hz) respectively. Mainly used in factories and power systems to receive and distribute electrical energy and to control, protect and monitor circuits. Its main feature is that it can be...
Description
The rated voltage and frequency of KYN61-40.5 metal clad enclosed high voltage switchgear are 40.5KV, 50(60Hz) respectively. Mainly used in factories and power systems to receive and distribute electrical energy and to control, protect and monitor circuits.
Its main feature is that it can be equipped with vacuum circuit breakers or SF6 circuit breakers, and the cabinet adopts an assembled structure, which improves product quality and matching accuracy.
This product is divided into two parts: cabinet and handcart. The cabinet is made of bent steel plate and assembled with bolts after spraying. According to functional characteristics, it can be divided into relay instrument room, handcart room, cable room and busbar room, etc., and each part is separated by grounded metal partitions.
The protection grade of the cabinet shell is IP4X. The door of the handcart is open, and the protection level is IP2X.
No | Item | Unit | Data | |
1 | Rated voltage | kV | 36/38/40.5 | |
2 | Rated current | A | 630, 1250,1600,2000,2500 | |
3 | Rated frequencty | Hz | 50/60 | |
4 | Rated short circuit breaking current | kA | 20, 25,31.5 | |
5 | 4s rated short circuit time withstand current | kA | 20, 25,31.5 | |
6 | Rated short circuit making current (peak) | kA | 50, 63,80 | |
7 | Rated peak withstand current (peak) | kA | 50, 63,80 | |
8 | Insulation Level | Rated lightning impulse withstand voltage | kV | 185(across open contacts:215) |
Main circuit 1 min power frequency withstand voltage | kV | 95(across open contacts:110) | ||
Auxiliary circuit 1 min power frequency withstand voltage | kV | 2 | ||
9 | Outline dimension W*D*H | mm | 1200/2600/2400 (Model:C) 1400/2800/2600 (Model: S) | |
10 | Protection degree | IP3X(compartment IP2X) | ||
11 | Weight | kg | 1000-1850 | |
Certificates
Packing & Delivery
Generally, we will use wooden packaging suitable for long-distance transportation such as sea transportation. We can also customize special packaging according to customer requirements.
Tip: Please check the product specifications and models in detail when ordering. When ordering non-standard products, you need to provide structure, parameters, standards, uses, etc. If you have previous ordering experience, please provide detailed parameters such as wiring diagram, wiring method, schematic diagram and model.
