400V Hybrid Split Phase Inverter Afore Inverter 5kW Solar Inverter Hybrid Grid System

400V Hybrid Split Phase Inverter Afore Inverter 5kW Solar Inverter Hybrid Grid System





1. Introduction to photovoltaic inverters

Photovoltaic inverter is a device that converts direct current (DC) generated by photovoltaic solar panels into alternating current (AC). In the process of constructing and operating photovoltaic power plants, the inverter in electrical equipment plays a very important role. Like photovoltaic power generation system technology, it continuously improves operational efficiency and conversion power, and combines with photovoltaic modules and other power generation equipment to form the most efficient photovoltaic system.

Usually, the process of converting DC electrical energy into AC electrical energy is called inverter, the circuit that completes the inverter function is called inverter circuit, and the device that implements the inverter process is called inverter equipment or inverter.

Inverters, also known as power regulators, can be divided into two types based on their use in photovoltaic power generation systems: independent power supply and grid connected. There are various types of inverters, so special attention should be paid when selecting the model and capacity. Especially in solar power generation systems, the efficiency of photovoltaic inverters is an important factor determining the capacity of solar cells and battery capacity.



2. Working principle of photovoltaic inverter

1) DC input: The DC input of the photovoltaic inverter is the direct current generated by the solar panel. These solar panels are typically composed of multiple solar cells, each generating a certain voltage and current.

2) Maximum Power Point Tracking (MPPT): The photovoltaic inverter is equipped with a Maximum Power Point Tracking (MPPT) controller, which is used to monitor the output voltage and current of the solar panel in real-time, and adjust their operating points to obtain maximum power output.

3) Boost circuit: The direct current of the solar panel enters the boost circuit after passing through the MPPT controller. The boost circuit adjusts the voltage and current to meet the requirements of the internal circuit of the photovoltaic inverter.

4) Inverter: The direct current passing through the boost circuit enters the inverter. The inverter converts direct current into standardized alternating current by using AC switching devices (usually MOSFETs or IGBTs). At the same time, the inverter also adjusts the phase, frequency, and voltage according to the requirements of the power grid.

5) Network connection: The AC power output from the inverter can be connected to the power grid to provide electricity for household, industrial, or commercial use. The inverter ensures that its output is synchronized with the grid and meets the voltage, frequency, and power requirements of the grid.

6) Control and protection: The photovoltaic inverter is also equipped with various control and protection functions, such as temperature monitoring, short circuit protection, overload protection, etc. These functions focus on ensuring the safe operation of photovoltaic inverters and improving the reliability and stability of the system.

Overall, inverters not only have direct to AC conversion functions, but also have the function of maximizing the performance of solar cells and system fault protection. In summary, there are automatic operation and shutdown functions, maximum power tracking control function, anti separate operation function (for grid connected systems), automatic voltage adjustment function (for grid connected systems), DC detection function (for grid connected systems), and DC grounding detection function (for grid connected systems).







PRODUCTS



Single Phase On-Grid lnverter

Three Phase On-Grid lnverter

Single Phase Hybrid lnverter

Three Phase Hybrid lnverter

Battery Pack & Solution(HV)

Battery Pack & Solution (LV)

All In One Energy Storage System





Specifications

Model	LOSUN-8K-SG04LP3	LOVSUN-10K-SG04LP3	LOVSUN-12K-SG04LP3
Battery Input Data
Battery Type	Lead-acid or Li-Ion
Battery Voltage Range (V)	40-60V
Max. Charging Current (A)	190A	210A	240A
Max. Discharging Current (A)	190A	210A	240A
Charging Curve	3 Stages / Equalization
External Temperature Sensor	Optional
Charging Strategy for Li-Ion Battery	Self-adaption to BMS
PV String Input Data
Max. DC Input Power (W)	10400W	13000W	15600W
PV Input Voltage (V)	550V(150V~800V)
MPPT Range (V)	200V-650V
Start-up Voltage (V)	160 V
PV Input Current (A)	13A+13A	26A+13A	26A+13A
No.of MPPT Trackers	2
No.of Strings Per MPPT Tracker	1+1	2+1	2+1
AC Output Data
Rated AC Output and UPS Power (W)	8000W	10000W	12000W
Max. AC Output Power (W)	8800W	11000W	13200W
Peak Power (off grid)	2 times of rated power, 10 S
AC Output Rated Current (A)	12A	15A	18A
Max. AC Current (A)	18A	23A	27A
Max. Continuous AC Passthrough (A)	50A
Output Frequency and Voltage	50/60HZ； 230/400Vac (Three phase)
Grid Type	Three Phase
Current Harmonic Distortion	THD<3% (Linear load<1.5%)
Efficiency
Max. Efficiency	97.60%
Euro Efficiency	97.00%
MPPT Efficiency	99.90%
Protection
PV Input Lightning Protection	Integrated
Anti-islanding Protection	Integrated
PV String Input Reverse Polarity Protection	Integrated
Insulation Resistor Detection	Integrated
Residual Current Monitoring Unit	Integrated
Output Over Current Protection	Integrated
Output Shorted Protection	Integrated
Output Over Voltage Protection	Integrated
Surge protection	DC Type II/ACType II
Certifications and Standards
Grid Regulation	IEC61727, IEC62116, IEC60068, IEC61683, NRS 097-2-1
Safety EMC / Standard	IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-11,1EC61000-3-12
General Data
Operating Temperature Range (°C)	-25~60°C, >45°C Derating
Cooling	Smart cooling
Noise (dB)	<30 dB
Communication with BMS	RS485; CAN
Weight (kg)	36.8
Size (mm)	422Wx658Hx281D
Protection Degree	IP65
Installation Style	Wall-mounted
Warranty	5 years





1.Pure sine wave inverter
2. Inverter running without battery
3.Built-in MPPT solar controller
4.Configurable input voltage range for home appliances and personal computers via LCD setting
5.Configurable battery charging current based on applications via LCD setting
6.Configurable AC/Solar Charger priority via LCD setting
7.Compatible to mains voltage or generator power
8.Auto restart while AC is recovering
9.Overload/ Over temperature/ short circuit protection
10.Smart battery charger design for optimized battery performance
11. Cold start function





















This product is usually customized.
We are a manufacturer and have a professional technical department that can design and provide solutions according to customer needs.
Please click on the button below to send us the information, and our sales personnel will contact you to provide you with the design drawings

Here are our customer examples for your reference



IF NEED MORE DETAILES,PLEASE FEEL FREE YO CONTACT US
