SCB10-30KVA/10Kv/0.4Kv Epoxy Resin Cast Dry Type Transformer
Aug 25, 2023
SCB10-30KVA/10Kv/0.4Kv epoxy resin cast dry type transformer
10 kV level "dry transformer", all of which are represented as SCB10-30KVA/10Kv/0.4Kv epoxy resin cast dry transformer. Among them, S refers to three-phase, C refers to epoxy resin casting, and B refers to low-voltage foil coils that can be used.
Safe, non flammable, and fire resistant, it can be directly installed in the load center.
2. Maintenance free, easy to install, and low operating cost.
3. It has good moisture resistance and can operate normally at 100% relative humidity.
4. Low loss, low noise, small partial discharge, usually 5% to 10% lower than the corresponding national standards.
5. Good heat dissipation, strong overload capacity, and can overload 50% under air-cooled conditions.
6. Reliable operation, with a comprehensive temperature protection and control system to ensure safe operation of the transformer.
7. Small size, light weight, stable structure, and strong resistance to sudden short circuits.
Price of 30kva dry type transformer
Due to different materials and production processes, the price may vary from manufacturer to manufacturer, usually within ten thousand yuan. For specific details, it is necessary to consult the transformer manufacturer in a timely manner.
PRODUCT LINK
http://www.switchgear-china.com/power-distribution-transformer/dry-type-transformer/dry-type-amorphous-metal-core-transformer.html
PRODUCT PHOTO
This product is usually customized.
We are a manufacturer and have a professional technical department that can design and provide solutions according to customer needs.
Please click on the button below to send us the information, and our sales personnel will contact you to provide you with the design drawings
Here are our customer examples for your reference
Russian clients
Data sheet N° 2-A: Transformer H61 33 kV/400V of 160 kVA
|
DESIGNATIONS |
S UNITS |
SPECIFIC DATA |
CANDIDATE DATA |
|
Maker |
|
To be indicated |
|
|
Reference standard |
|
IEC 60076 |
|
|
Type |
|
Phase |
|
|
Vat |
|
Hermetic |
|
|
Execution |
|
Tropicalized |
|
|
Dielectric |
|
PCB-free oil |
|
|
Installation |
|
On pole |
|
|
Operating ambient temperature |
°C |
45 |
|
|
Rated frequency |
Hz |
50 |
|
|
Rated power |
Kva |
160 |
|
|
Rated primary voltage |
Kv |
33 |
|
|
Isolation level assigned to primary school |
Kv |
36 |
|
|
Number of phases in primary school |
|
03 |
|
|
Secondary voltage |
V |
400/230 |
|
|
Voltage adjustment range on the M side when unladen |
% |
±2.5 |
|
|
Coupling |
|
Yzn11 |
|
|
Short circuit voltage |
% |
4 - 4.5 |
|
|
Neutral sized for one load |
% |
100 |
|
|
Maximum vacuum losses |
W |
230 – 460 |
|
|
Losses due to Maxi load |
W |
1450 - 2350 |
|
|
Maximum steady-state oil temperature |
°C |
55 |
|
|
Maximum temperature of the windings in steady state |
°C |
60 |
|
|
Winding material |
|
Electrolytic copper |
|
|
Maximum noise level |
Db |
52 |
|
|
50Hz industrial frequency hold, 1 min |
Kv |
50 - 70 |
|
|
Shock wave resistance (1.2/50 micros) |
Kv |
125 - 170 |
|
|
Cooling |
|
ONAN |
|
|
Nameplate |
|
01 |
|
|
Grounding connection |
|
01 |
|
|
Dimensions Height/width/depth |
mm x mm x mm |
1200 X 1050 X 710 |
|
|
Total mass of transformer including oil |
Kg |
400 |
|
|
Oil mass |
Kg |
90 |
|
|
PAINT |
|
||
|
|
|
Tropicalized and anti-rust |
|
|
|
|
Layers |
|
|
|
|
Binder |
|
|
|
|
Colour |
|
|
|
|
Plans and technical diagrams to be provided. |
|
IF NEED MORE DETAILES,PLEASE FEEL FREE YO CONTACT US
