GZD DC Panel 110v Low Voltaeg Switchgear

Technical specification

Rated input voltage: AC380~415V
Range of input voltage: AC323~475V
Frequency: 50Hz ± 10%
Power factor: 0.92
Rated output voltage: DC110V or DC220V
Range of output voltage: DC99~143V (DC110V), DC198~286V (DC220V)
Rated output current: 10A~240A (DC, N+1)
Equalizing coefficient: ≤ 5%
Voltage stabilizing accuracy: ≤ 0.5%
Current stabilizing accuracy: ≤ 1%
Ripple coefficient: ≤ 0.5%
Efficiency: ≥94%
Noise: ≤50db (1m away from the panel)

Service environment

Ambient temperature:

Maximum +40°C
Maximum 24 hour average +35°C
Minimum (according to minus 15 indoor classes) -10°C

Ambient humidity:

Daily average relative humidity less than 95%
Monthly average relative humidity less than 90%
Height above sea level at site less than 2000m
Earthquake intensity less than 8 degree

This product should not be used under conditions of fire, explosion, earthquake and chemical corrosion environments.
