outdoor KYN28A high voltage switchgear

Sep 26, 2022

Specification

Item	Unit	Parameter
Rated Voltage	kV	3.6, 7.2, 12
Rated Frequency	Hz	50, 60
Circuit Breaker Rated Current	A	630,1250,1600,2000,2500,3150
Switchgear Rated Current	A	630,1250,1600,2000,2500,3150
Rated Short TIme Withstand Current(4s)	kA	20,25,31.5,40
Rated Peak Withstand Current	kA	50,63,80,100
Rated Short Circuit Break Current	kA	20,25,31.5,40
Rated Short Circuit Closing Current (Peak)	kA	50,63,80,100
Rated Insulation Level 1min Power Frequency Withstand Voltage (to pole)	kV	24,32,42
Rated Insulation Level 1min Power Frequency Withstand Voltage (to break)	kV	24,32,42
Lightning Impulse Withstand Voltage(Peak) (to pole)	kV	40,60,75
Lightning Impulse Withstand Voltage(Peak) (to break)	kV	24,32,42
Protection Degree		IP4X,IP2X

KYN28A-12(6)

KYN28A-12(7)

KYN28A-12
