GCKMNS/GCS series Low voltage switchgear(hereinafter short as switchgear)is a complete power distribution device for 3.6~24kV,3-phase AC 50Hz,single-bus and single-bus sectionalized system. It is mainly used for power transmission of middle/small generators in power plants; power receiving, transmission for substations in power distribution and power system of factories, mines and enterprises, and starting of large high-voltage motor, etc.,so as to control, protect and monitor the system. The switchgear meets IEC298,GB3906-91.In addition to be used with domestic VS1 vacuum circuit breaker, it can also be used with3AH5 from Siemens domestic ZN65A,and VB2 from GE, etc.,it is truly a power distribution device with good performance. In order to meet the requirement for wall mounting and front-end maintenance, the switchgear is equipped with a special current transformer, so that the operator can maintain and inspect it in front of the cut
Operating environment:
1)Ambient temperature:-10°C-+40°C;
2)Altitude: high voltage ≤1000Meter, low voltage ≤2500Meter (technical department will design specially if exceeds);
3)Relative humidity:≤85%
4)Seismic intensity:≤ magnitude 8;
5Apply to the places have no fire,no explosion danger, no serious pollution,no chemical corrosion and no violent vibration.
LV switchgear
Executive standard:
GB7251 Low voltage complete set switchgear and control device
GB3906-2006 3.6kV~40.5kV AC metal enclosed switchgear and control device
Parameter | ||||
Rated voltage | V | 400 | 690 | |
Rated insulation voltage | V | 690 | 1140 | |
Rated impact withstand voltage | V | 6000 | 10000 | |
Rated working short circuit breaking ability | kA | 18~100 | 10~75 | |
Rated utmost short circuit breaking ability | kA | 25~120 | 20~85 | |
Rated frequency | Hz | 50/60 | ||
Rated current | A | 400,500,630,800,1000,1250,1600,2000,2500,3150,4000,5000,6300 | ||
Rated control power | V | AC 110/220/380,DC 110/220 | ||
Dimension (Unit:mm) | MNS/GCS/GGD | width | 400,600,800,1000,1200 | |
depth | 600,800,1000 | |||
height | 2200 | |||
