Compact Substation

This substation is a very important power distribution and power supply unit in the cable network. It is a complete power supply with HV control, protection, conversion, and power distribution. It is used for three-phase AC 50Hz and maximum rated current. 1600KVA transformer. It is widely used in industrial and mining enterprises, residential communities, hospitals, shopping malls, high-rise buildings and other power distribution systems.

For this substation, we mainly produce and export 11KV, 15KV, 20KV, 24KV, 33KV types.

For customized special types, once we obtain clear technical data or single-line diagrams (SLD), we can also make them.

Conditions of Use

1. The highest ambient temperature does not exceed 45℃, and the lowest does not exceed -45℃;

2. The height should not exceed 1000m. If special customized transformers and low-voltage components are used, the height can reach 4000m;

3. Place it in a place where the vertical tilt angle does not exceed 5° and there is no severe vibration or impact;

4. The air humidity is not more than 90% (+ 25℃);

5. The gas place must not conduct dust, explosion hazard, corrosion of metal and electrical components;

6. The outdoor wind speed shall not exceed 35m/s.

7. If the above-mentioned normal use environmental conditions are exceeded, the customer can customize it from our company.

Order instructions

1. Conceptual diagram of main circuit or electrical schematic diagram.

2. Model, specification and quantity of main components.

3. Way of incoming and outgoing wires, cable specifications, etc

4. Shell material and appearance: composite plate, steel plate, stainless steel plate, etc.

5. Other order requirements.
