JP LV Electric 450V Power Distribution Board
JP type power feeder pillar switchgear is withith the strong assistance of our adept professionals, we are engrossed in supplying a large variety of Feeder Pillar Panel. The offered panel is Integrated with power distribution/metering/protection/control/reactive power compensation function. This panel is extensively used in commercial and residential sectors for low voltage distribution applications. Before offering to the clients, this panel is stringently tested in order to ensure its flawless performance. Comply with standard IEC439
Description
JP LV electric 450V power distribution board
Characteristics
JP type switchgear was made of 2mm high quality stainless steel plate after multiple bending flanging process ( flame retardant, environmental protection, heat insulation, anti-condensation performance), using special stainless steel welding process, the overall strength after molding, the surface smooth as a mirror, do not leave weld marks; internal installation of beam (plate) for the hot galvanizing process, to ensure that the twenty years do not rust; the front and rear doors, easy operation and maintenance, the door was edged with high elastic aging sealant, each door is equipped with two types of lock, padlock with anti rain cover wall rust; whole closed with a sealing device measuring room; the side of the box is equipped with cable lines into the proof of foreign body wear tube, bottom ventilation holes and the cable outlet hole is arranged at the top of ventilation and screen, waterproof Anti rust, dustproof, anti-foreign object function, protection grade: lP54.
1. Altitude above sea level should not exceed 2000 meters.
2. Ambient air temperature: -5℃~+40℃ and the average temperature should not exceed +35℃ in 24h.
3. Air condition: With clean air. Relative humidity should not exceed 50% at +40℃.
Higher relative humidity is allowed at lower temperature. Ex. 90% at +20℃.
4. Places without fire, explosive danger, serious pollution, chemical corrosion and fierce vibration.
5. Installation gradient not exceed 5℃.
6. Control center is suitable to the transportation and store with following temperature:-25℃ ~+55℃, in short time (within 24h) it should not exceed +70℃
Specfication
| No. | Description | ||
| 1 | Busbar Rating | A | 630 |
| 2 | Busbar material | Copper | |
| 3 | Type of protection used on busbars against corrosion (e.g. heavily tinned) | Tinned Plating | |
| 4 | Dimensions of busbars ( L x W x Thickness) | mm | 660 x 50x 5 |
| 5 | Method of connection between busbars and cable lugs (cable lugs not to be provided) | Bolted Type | |
| 6 | Fixing centre of HRC fuse | mm | 90 |
| 7 | Are safety barriers fitted between phases of the same incoming or outgoing unit? | Yes | |
| 8 | Are insulating shields fitted between adjacent units? | No | |
| 9 | Minimum clearance between the lowest cable connection and ground level | mm | 300 |
| 10 | Material used for housing | Hot Dipped | |
| Galvanized Sheet | |||
| 11 | Treatment of housing against atmospheric corrosion | 7 Tank Process | |
| 12 | Padlocking facility on housing door | Yes | |
| 13 | Dimensions of complete housing (Root included) Height x width x depth | mm | 1475x1300x500 |
| 14 | Weight of complete feeder pillar | 210kg |
Technical parameter
No. | The name of the | units | parameter |
1 | Variational pressure capacity | KVA | 30-400 |
2 | Rated working voltage | V | AC400 |
3 | Operating voltage of the auxiliary circuit | V | AC220, AC380 |
4 | Rated frequency | Hz | 50 |
5 | Rated current | A | 630 |
6 | Rated leakage operating current | mA | 30-300adjustable |
7 | Protection grade | IP54 |
WORKSHOP
CERTIFICATE
EXHIBITION
COMPANY OVERVIEW
FAQ
Q5 : Is OEM/ODM available?
A: Yes, it is! Our products can be Customized. We have design and engineer teams,we can customize products according to customers' drawing or requirements.
Q6 : You are manufacturer or trading company?
A: We are factory, As a 100% professional manufacturer with 20 year's manufacturer experience, we could produce products according to customers' requirements and we could also control the quality of products 100%.
Q7 : Can the price be negotiated?
A: Yes, the price is negotiable. It can be changed according to your quantity or package
Q8 : How about inspection?
A: We have the whole inspection system from raw material to end products include temperature rise test,salt spraying test conductor type test,mechanical life test.
Q9 : What is payment terms?
A: T.T, Paypal,Western Union,Alibaba trade assurance and L/C is acceptable. 30% T/T in advance ,70% balance before shipment.
