Low Voltage Switchgear /Electric Cabinet/ Power Distribution Use Metal-Clad Enclosed Switchgear
GGD AC low voltage power distributing cabinet is applicable to power distribution system of AC 50HZ, and with a rated operational voltage of 380V,rated operation current to 3150A in power users like generators,transformer substation,and mining enterprises,and it is used in power...
Description
GGD AC low voltage power distributing cabinet is applicable to power distribution system of AC 50HZ, and with a rated operational voltage of 380V,rated operation current to 3150A in power users like generators,transformer substation,and mining enterprises,and it is used in power transformation,distribution and control of driving motor,illumination and power distribution equipments.
Conditions for use
Ambient air temperature shall not be higher than 40°C and not lower than -5°C.The average temperature within 24 hours shall not be higher than 35°C.
Indoor installation and use, the altitude of the use site shall not exceed 2000m.
The ambient air relative humidity shall not exceed 5% when the highest temperature is 40°C, and it shall be allowed to have a large relative humidity at a lower temperature.(for example, 90% at 20°C) the effect of occasional condensation due to temperature changes should be taken into account.
The inclination of the equipment with the vertical plane shall not exceed 5°.
The equipment shall be installed in a place free from violent vibration and impact, and in a place not strong enough to cause corrosion of electrical components.
Switchgear Structure
The Specification
| Item | Unit | Parameters | |
| Rated Working Voltage | V | 400 | |
| Rated Frequency | Hz | 50/60 | |
| Rated Current | Horizontal Bus Line | A | ≤400 |
| Vertical Bus Line | A | ≤1000 | |
| Rated Short-time Tolerant Current(1s) | kA | 50 | |
| Rated Peak Tolerant Current | kA | 105 | |
| Dielectric Strength | V/1min | 2500 | |
| Rated Insulation Voltage | V | 660 | |
| Out Shell Protection Level | IP30/IP40 | ||
| Dimension | MM | (600-1000)×1000×2200 |
Our Factory:
Others Products:
About us:
Henan Fengyuan Power Technology Co., Ltd., founded in 2010 with registered capital of 20 million yuan, a fixed asset of 50 million yuan, more than 200 employees and an annual output value of nearly 100 million yuan, located in Jiyuan City, Henan, China.
Fengyuan focuses on producing KYN61-40.5 power distributing cabinet, KYN28-12, XGN15-12, HXGN15-12 and other model medium and high voltage electric full set switchgear equipment, movable transformer prefabricated substation, generator automatic controlling cabinet, dual power automatic switching device, draw-out low voltage switchgear GCK, GCS, MNS series, fixed low voltage switchgear GGD series, and other controlling, metering, switching box or cabinet series products.
FAQ:
1) Q:Is your price Competitive?
We have our own Factory. Thanks to strong production and distribution system, we promise to offer our customers the most competitive price.
2) Q: How about the delivery time?
A:Usually we need about 6-20 days produce time. 15-20 days after receiving the full payment.
3) Q: What about the guarantee?
All products before delivery to provide a certificate of product quality,24hours after sale service for you service.
4) Q: What's the payment method?
A:30%T/T as Deposit, Balance 70%TT before products leave our factory.
