12kv Switchgear
12kv Switchgear KYN28 series switchgears are used to receive and distribute electrical energy, and to control, protect, monitor and measure power circuits. Brand:Fengyuan Power Item NO.:KYN28 MOQ:1 Payment: FOB, C&F, CIF, etc. Product Origin:Henan,China Color:Any, accept customization...
Description
12kv Switchgear
KYN28 series switchgears are used to receive and distribute electrical energy, and to control, protect, monitor and measure power circuits.
Brand:Fengyuan Power
Item NO.:KYN28
MOQ:1
Payment: FOB, C&F, CIF, etc.
Product Origin:Henan,China
Color:Any, accept customization
Shipping Port: Qingdao Port, Shanghai Port, etc.
Lead Time: 30 days
| NAME | UNIT | DATA | ||
| Rated Voltage | kV | 3.6、7.2、12、24 | ||
| Rated Frequency | Hz | 50/60 | ||
| Breaker rated current | A | 630/1250/1600/2000/2500/3150/4000 | ||
| Rated current of switchgear | A | 630/1250/1600/2000/2500/3150/4000 | ||
| Rated peak withstand current | kA | 50/63/80 | ||
| Rated short-time withstand current (4s) | kA | 16/20/25/31.5/40/50 | ||
| Rated peak withstand current | kA | 40/50/63/80/100/125 | ||
| Rated short-circuit breaking current | kA | 16/20/25/31.5/40/50 | ||
| Rated short-circuit closing current (peak) | kA | 40/50/63/80/100/125 | ||
| Rated insulation level | 1min frequency withstand voltage | Interpolar, interpolar | kV | 24/32/42 |
| Interfracture | kV | 24/32/42 | ||
| Lightning surge withstand voltage (peak) | Interpolar, interpolar | kV | 40/60/75 | |
| Interfracture | kV | 46/70/85 | ||
The best choice for the electrical industry! ! !
Please leave an inquiry for more detailed information about prices, packaging, shipping and discounts.
