FYG12 Compact Solid Insulated Ring Main Unit
FYG12 compact solid insulated ring main unit switchgear mainly has three functional unit modules, namely D unit (circuit breaker unit), I unit (load switch unit) and R unit (fuse combined electric unit). The main switch of each unit is a vacuum switch. When the distribution network system...
Description
FYG12 compact solid insulated ring main unit switchgear mainly has three functional unit modules, namely D unit (circuit breaker unit), I unit (load switch unit) and R unit (fuse combined electric unit). The main switch of each unit is a vacuum switch. When the distribution network system requires a combination of multiple units, it can be expanded arbitrarily according to the requirements of the distribution network. Arbitrarily arrange according to different design schemes to meet different power distribution network requirements.
Environmental conditions
(1) Applicable altitude: ≤2000m
(2) Temperature: -40℃~+55℃ relative
(3) Humidity: daily average ≤95%, monthly average ≤90%
(4) Earthquake damage level: ≤8
| D Unit | I Unit | R Unit | ||||||
| Rated voltage(kv) | 12 | 24 | 12 | 24 | 12 | 24 | ||
| Rated frequency (Hz) | 50 | 50 | 50 | |||||
| Rated current(A) | 800 | 630 | 630 | 630 | ||||
| Rated short-circuit breaking current(KA) | 25 | 20 | 20 | 31.5 | ||||
| Rated cable charging breaking current(A) | / | / | 10 | 10 | ||||
| Rated short-time withstand current(KA) | 25 | 20 | 20 | / | ||||
| Rated short-time withstand time(S) | 4 | 4 | / | |||||
| Rated peak withstand current(KA) | 63 | 50 | 50 | / | ||||
| Rated short-circuit closing current (KA) | 63 | 50 | 50 | / | ||||
| Rated breaking transfer current(A) | / | / | 3150 | |||||
| Rated insulation level | Rated lightning impulse withstand voltage(kv) | Interphase / relatively | 75 | 125 | 75 | 125 | 75 | 125 |
| Break | 85 | 145 | 85 | 145 | 85 | 145 | ||
| Rated power frequency withstand voltage(kv1min) | Interphase / relatively | 42 | 65 | 42 | 65 | 42 | 65 | |
| Break | 48 | 79 | 48 | 79 | 48 | 79 | ||
| Auxiliary control loop | 2 | 2 | 2 | |||||
| Mechanical life (times) | 10000 | 10000 | 10000 | |||||
| DC resistance of main circuit (µΩ) | ≤140 | ≤140 | ≤140 | |||||
Advantages ring main unit:
Separate-phase modular design
Outer surface of poles painted semi-conductive layer and earthed
Pressure relief port on insulating box(switching compartment)
Fully solid insulated and sealed design
Unique internal structure design
Complete application solution, free combination
Smart application
High altitude application
