What Standards Should Be Met For Measuring The Water Content in The Insulation Oil Of Oil Immersed Transformers?

What standards should be met for measuring the water content in the insulation oil of oil immersed transformers?

The moisture content in transformer oil plays an important role in insulation technical supervision, and is one of the important indicators for testing the qualification of oil products.

The presence of water can affect the electrical performance of oil products, such as dielectric loss factor and breakdown voltage. In addition, the presence of water can also promote oil aging, leading to a decrease in the reliability and service life of electrical equipment.

Testing the water content can monitor the internal insulation status of oil-filled electrical equipment in operation, detect potential faults within the equipment as soon as possible, and make judgments on the nature of the faults to eliminate hidden dangers and ensure safe and reliable operation of the equipment.

What standards should be met for measuring the water content in the insulation oil of oil immersed transformers? Let's take a look at the regulations first.

According to GB50150-2016 Standard for Hand over Test of Electrical Equipment, 8.0.3 Test of insulating oil in oil immersed transformers and SF6 gas in SF6 gas insulated transformers, the measurement of water content in transformer oil in Article 3 shall comply with the following provisions:

1. When the voltage level is 110 (66) kV, the water content in the oil should not exceed 20mg/L;

2. When the voltage level is 220kV, the water content in the oil should not exceed 15mg/L;

3. When the voltage level is 330kV-750kV, the water content in the oil should not exceed 10mg/L;
