Oil Immersed Transformer Status Monitoring And Cloud Based Alarm System

Oil immersed transformer status monitoring and cloud based alarm system

In order to ensure the safe and stable operation of oil-immersed transformers, data such as oil temperature, oil level, current, voltage, etc. are often monitored. A suitable online monitoring system for transformer status is needed, which can monitor various key parameters of equipment operation at any time, understand equipment status in a timely manner, and quickly alarm in case of abnormal faults, manage and control in a timely manner, thereby effectively improving the reliability of transformer operation.

The industrial intelligent gateway can collect transformer environmental data and transformer indicator data, connect to the monitoring platform, and monitor, display, and analyze the data; At the same time, abnormal data is transferred to the alarm module, real-time alarm notifications and maintenance work orders are generated, and sent to management personnel at all levels, effectively solving the lag problem of transformer fault detection and processing, and improving the efficiency of operation and maintenance management.

system function

1. Device data collection

Real time collection of data such as oil temperature, oil level, pressure, current, voltage, etc. on cloud platforms (such as IoT Bolian Cloud, enterprise self-developed cloud, Alibaba Baidu Huawei, etc.), supporting 5G/4G/WIFI/Ethernet and other internet access methods.

2. Fault abnormal alarm

Automatically generate alarm notifications in case of data abnormalities or equipment failures, support WeChat, SMS, email, and other methods, and generate work order records to be distributed to engineers.

3. Remote programming maintenance

Engineers perform remote programming and debugging, as well as remote uploading and downloading of programs, on remote devices to improve maintenance efficiency, making it convenient and efficient.

4. Data report analysis

The data reports of various devices and time periods can be quickly queried, exported, and printed, making it convenient for managers to analyze and improve the usage and maintenance of equipment.

Traduction pour : Transfo H61 20KV 160kVA B2

H61 Transformer 15(20)kV 160kVA B2

Three-phase MV / LV distribution transformer with MV and LV windings in wound copper power P = 160KVA
- Compliance: NFC 52 100 - 52 112 and 52 113 standard or equivalent in substance
- Natural cooling: ONAN
- MV voltage adjustment: by switch off +/- 5% in five (5) positions
- Type: on post H61
- Nominal power: 160KVA
- Primary rated voltage: 20,000V ± 5%
- Secondary voltage: 410V off-load between phases / 240V between phase and neutral
- Frequency: 50Hz
- Short-circuit voltage: 4%
- No-load loss less than or equal to 300W
- Load loss less than or equal to 2000W
- Coupling: Dyn11 with output neutral
- MV and LV crossings: in porcelain


PRODUCT LINK

http://www.switchgear-china.com/power-distribution-transformer/oil-immersed-transformer/high-voltage-oil-immersed-distribution.html

PRODUCT PHOTO

This product is usually customized.
We are a manufacturer and have a professional technical department that can design and provide solutions according to customer needs.
Please contact our sales personnel to obtain design drawings

Here are our customer examples for your reference
