Pull-out operation of GCS withdrawable switchgear

Pull-out operation of GCS withdrawable switchgear:

1. Turn the main switch handle to the disconnected position.

2. Press the red interlocking mechanism on the upper left of the drawer handle with one hand.

3. Pull the drawer out.

GCS withdrawable switchgear is used in power plants, substations, petrochemicals, metallurgical steel rolling, light industry and textiles and other factories and mines, as well as residential quarters, high-rise buildings and other places. It is used for power conversion, distribution and control of power distribution equipment in power systems with AC 50~60Hz and rated working voltage AC 660V and below.
