Low Voltage Electrical Control Panel Board
The rated current of the XL power distribution cabinet can reach 630A. The shell is made of steel or stainless steel. The surface is generally painted or electrostatic sprayed. The switch in the cabinet can use knife switches, molded case circuit breakers, and loads. Switch etc. XL type power...
Description
Low Voltage Electrical Control Panel Board
The rated current of the XL power distribution cabinet can reach 630A. The shell is made of steel or stainless steel. The surface is generally painted or electrostatic sprayed. The switch in the cabinet can use knife switches, molded case circuit breakers, and loads. Switch etc.
XL type power distribution cabinet has the characteristics of compact structure, convenient maintenance, and flexible combination of circuit schemes. The door can be equipped with voltmeters, ammeters and other measuring instruments, operating appliances, signal appliances, etc. according to requirements. It is a power distribution device with simple structure, reliable operation and low cost.
The XL-21 power boxes are widely used in power plants and industrial and mining enterprises in the following three-phase AC 500V three-phase three-wire, three-phase four-wire, three-phase fivelines and distribution systems for power or lighting distribution purposes, the Department of indoor wall installation, front panel operation, maintenance front panel; cabinet is fully enclosed structure, assembled from C profiles or profiles made 8MF. Box using the new rotary load isolation switch, with a load operation, equipped with voltage, current indication instruments and lights, buttons, switches, etc. on the front door so that the main element. The distribution box using the new self-designed components, compact, elegant design, easy maintenance, a variety of wiring schemes to choose from
Working environment conditions:
*Ambient air temperature: -15°C-+40°C;
*Relative humidity: Daily average ≤ 95%,and daily average of water vapor pressure < 2.2kPa;
Monthly average ≤ 90%,and monthly average of water vapor pressure < 1.8kPa;
*Altitude: ^ 1000m;
*Seismic intensity: No more than 8 degree
*Ambient air should be free of pollution of corrosive or flammable gas or vapor;
*No obvious vibration;
Main technical parameters | |||
Sequence number | Project Name | Unit | Electrical parameters |
1 | standards | GB 7251.1-2005 | |
2 | The rated voltage insulation Ui | V | 690V |
3 | Rated voltage Ue | V | 400V |
4 | Rated current In | A | 630A~100A |
5 | Short-term tolerance current ability lew | kA | 20KA |
6 | Shell IP protection grade | IP30/IP55/IP65 | |
7 | Environment temperature | °C | -20~+40 |
8 | installation | landing | |
9 | Case materials | mm | 1.5-2.0 Cold-rolled steel sheet or stainless steel plate |
10 | Surface treatment | Electrostatic spraying technology | |
11 | Open the direction | The opening Angle is equal or greater than 135 ° | |
PRODUCT PHOTO
Factory showing room
Certificates
Customer visit
COMPANY OVERVIEW
Jiyuan Fengyuan Electrical Equipment Co., Ltd was established in 1984 and is a designated enterprise specializing in the production of high and low voltage switch cabinets by the State Grid Corporation of China.
We have more than 30 years professional experience in high and low voltage complete switchgear cabinet,box type substation,transformer,etc, have CE,ISO, GB,CQC,certificate
Factory directly,Professional manufacturer, All can be customized according to your local requirement
Welcome to inquiry
FAQ
Q5 : Is OEM/ODM available?
A: Yes, it is! Our products can be Customized. We have design and engineer teams,we can customize products according to customers' drawing or requirements.
Q6 : You are manufacturer or trading company?
A: We are factory, As a 100% professional manufacturer with 20 year's manufacturer experience, we could produce products according to customers' requirements and we could also control the quality of products 100%.
Q7 : Can the price be negotiated?
A: Yes, the price is negotiable. It can be changed according to your quantity or package
Q8 : How about inspection?
A: We have the whole inspection system from raw material to end products include temperature rise test,salt spraying test conductor type test,mechanical life test.
Q9 : What is payment terms?
A: T.T, Paypal,Western Union,Alibaba trade assurance and L/C is acceptable. 30% T/T in advance ,70% balance before shipment.
Q10 : What is the service offered by company?
A: We have the professional engineer team which can design and develop the mold to arrive different customer requirement.
We also have the sales team to offer good service from pre-sale to after-sale.
This product is usually customized.
We are a manufacturer and have a professional technical department that can design and provide solutions according to customer needs.
Please contact our sales personnel to obtain design drawings
Here are our customer examples for your reference
IF NEED MORE DETAILES,PLEASE FEEL FREE YO CONTACT US
