KYN28A-12 6.3KV Electric Distributor Box

Name: China Customized KYN28A-12 6.3KV Electric Distributor Box Manufacturers, Suppliers - FENGYUAN
Brand: FENGYUAN
SKU: 193953022

KYN28A-12 is a relatively common high-voltage switchgear at present in China with full name- indoor metal armored removable switchgear. Its rated voltage is 3.6kV~12kV. The equipped vacuum circuit breaker is in the middle of the switch cabinet, that is, the circuit breaker is located in the middle of the front cabinet of the switchgear, so the lower space can be saved for the expansion of other schemes or used as a cable room.The switchgear meets IEC,GB3906-91.In addition to be used with domestic VS1 vacuum circuit breaker,　it can also be used with VD4 from ABB, 3AH5 from Siemens domestic ZN65A, and VB2 from GE,　etc.,it is truly a power distribution device with good performance.

Send Inquiry

Description

KYN28A-12 6.3KV electric distributor box

Product Features:

1. Safe and reliable: the compartments in the cabinet are all independent small compartments separated from each other; perfect "five prevention" interlocking function, reliably preventing misoperation and erroneous entry into the live interval; quick closing grounding switch to achieve reliable protective grounding. 2. Flexible solutions: The switch cabinet has a complete set of solutions, which can flexibly form various system solutions to meet customer requirements; according to the application environment and special requirements, it can also provide high altitude series products, double bus series and various non-standard solutions. 3. Strong practicability: the cabinet shell has high sealing strength to prevent the equipment from being invaded by sundries and insects.

Product Standard:

IEC298 "AC Metal-enclosed Switchgear and Control Equipment with Rated Voltage 1KV and Below" IEC694 "High Voltage Switch and Control Equipment Sharing Clause" GB3906 "3-36KV AC Metal Enclosed Switchgear" DL404 "Order Conditions for Indoor AC High Voltage Switchgear"

Application Channels:

Mainly used in power plants, substations, transformation and distribution centers of industrial and mining enterprises, and large-scale high-voltage motor starting equipment, etc., for receiving and distributing electric energy, and for controlling, protecting and monitoring circuits.

Conditions of Use:

1.The highest ambient temperature does not exceed +40℃, and the lowest does not exceed -10℃. 2.Environmental humidity: the daily average relative humidity is ≤95%, and the monthly average relative humidity is ≤90%. 3.The altitude does not exceed 1000m. 4.The earthquake intensity does not exceed 8 degrees.

FACTORY

CERTIFICATE

CQC

EXHIBITION

COMPANY OVERVIEW

PACKING&DELIVERY

baozhuang_

FAQ

Q5 : Is OEM/ODM available?

A: Yes, it is! Our products can be Customized. We have design and engineer teams,we can customize products according to customers' drawing or requirements.

Q6 : You are manufacturer or trading company?
A: We are factory, As a 100% professional manufacturer with 20 year's manufacturer experience, we could produce products according to customers' requirements and we could also control the quality of products 100%.

Q7 : Can the price be negotiated?

A: Yes, the price is negotiable. It can be changed according to your quantity or package

Q8 : How about inspection?

A: We have the whole inspection system from raw material to end products include temperature rise test,salt spraying test conductor type test,mechanical life test.

Q9 : What is payment terms?

A: T.T, Paypal,Western Union,Alibaba trade assurance and L/C is acceptable. 30% T/T in advance ,70% balance before shipment.
