Outdoor Box Type Prefabricated Combined Substation

Prefabricated transformer substation is a compact substation which combines high voltage switch system,low voltage distribution panel,distribution transformer,electric energy calculation part and power compensation device.

Service condition

1. Altitude: ≤1000m (above sea level)

2. Ambient temperature: highest and lowest 40C -25℃

The highest monthly average temperature: ≤35C

The highest annual average temperature: ≤25C

3. Relative humidity: daily average ≤95%, monthly average ≤90%

4. Maximum daily temperature difference: 25℃

5. Intensity of sunshine: 0.1W/CM2 (wind speed 0.5M/S);

6. Outdoor wind speed: ≤35m/s;

7. Pollution level: level three;

8. Rainproof grade: level 3;

9. The slope of the installation site should not be greater than 3°;

10. Seismic resistance: the ground horizontal acceleration is 0.2g

The ground vertical acceleration is 0.1g;

11. Installation site: There should be no fire/explosion hazard/severe pollution/chemical substances

Corrosion and subtle vibrations.

If the service conditions are different from the above conditions, the customer should negotiate with the manufacturer.

Feature

1. The frame of the substation is made of anticorrosive grooved steel and angle steel, so it is tough enough in terms of machinery and rigidity.

2. The shell material can be cold rolled steel plate, stainless steel plate, aluminum alloy plate, composite color plate.

3. The small rooms of the substation are divided into separate small rooms by steel plates. The small rooms can be arranged in various forms such as the Chinese characters "eye" and "level".

4. In order to facilitate monitoring and maintenance, the transformer room, high voltage room and low voltage room are all equipped with lighting devices.

5. The substation cover is designed with two layers to prevent heat radiation and increase the indoor temperature.

6. The transformer mainly uses natural ventilation. When the temperature exceeds the set value, the axial fan on the top will automatically start to control the room temperature of the transformer.

7. All rotating connecting parts are equipped with sealing devices, which have good moisture resistance.

8. Perfect protection performance, convenient operation, and perfect "five prevention" functions on the high-pressure side to ensure safe maintenance.

9. Compact structure, beautiful appearance, can be used in conjunction with the surrounding environment.

WORKSHOP

CERTIFICATE

EXHIBITION

COMPANY OVERVIEW

FAQ

Q5 : Is OEM/ODM available?

A: Yes, it is! Our products can be Customized. We have design and engineer teams,we can customize products according to customers' drawing or requirements.

Q6 : You are manufacturer or trading company?
A: We are factory, As a 100% professional manufacturer with 20 year's manufacturer experience, we could produce products according to customers' requirements and we could also control the quality of products 100%.

Q7 : Can the price be negotiated?

A: Yes, the price is negotiable. It can be changed according to your quantity or package

Q8 : How about inspection?

A: We have the whole inspection system from raw material to end products include temperature rise test,salt spraying test conductor type test,mechanical life test.

Q9 : What is payment terms?

A: T.T, Paypal,Western Union,Alibaba trade assurance and L/C is acceptable. 30% T/T in advance ,70% balance before shipment.

MORE VIDEO

Facebook

https://www.facebook.com/bob.niu.35/

Youtube

www.youtube.com/channel/UC5IP4dL0UTQG4fgAOa3UhWA

Twitter

https://twitter.com/FengyuanE

Ordering instruction:

1. Conceptual drawing or electrical schematic diagram of main circuit.

2. Model, specification and quantity of main components.

3. Incoming and outgoing line mode and cable specification, etc.

4. Shell material and appearance: composite plate, steel plate, stainless steel plate, cement plate, etc.

5. Other order requirements.
