12 kV Solid Insulated Metal Switchgear is suitable for middle voltage power distribution system and rated current is 630A/1250A. It is more reliable than the SF6 ring main unit, and is more suitable for a wider range of applications in both of GB standard and IEC standard.

Technical data:

1.Rated Voltage:12kV

2.Rated Frequency:50Hz

3.Rated Currency:630/1250A

4.Rated short-time power frequency withstand voltage (phase to ground)1min:42kV

5.Rated short-time power frequency withstand voltage (phase to ground):75kV

6.Rated short-circuit breaking current:25/31.5kA

7.Rated peak withstand current:25/31.5kA

8.Rated peak withstand current:63/80kA

Features

1.Safety

• All live parts are sealed or embedded in the epoxy resin and silicon rubber, fully insulated and wholly enclosed structure, safety protection level: IP67.

• Enhanced phase separation design, independent phase insulation to avoid the fault between phases.

• Switch working position of each phase could be observed independently, which improves operation safety.

2.Multi-environmental application

• Applicable to low temperature areas, high altitude areas, high humidity areas, high corrosion areas, low-lying areas and explosion forbidden places.

3.Flexibility

• Standard modular design to facilitate circuit extension, modification and replacement.

• Feasible to any replacement in both circumstances of any unit in fault and according user needs.

• Smaller dimension makes it more convenient to be moved, transported or replaced.

4.Environment-friendly

• Epoxy resin is employed instead of SF6.

Small volume, compact decoupling, convenient operation and maintenance
