HXGN-12 high-voltage switchgear is a box-type fixed metal-enclosed switchgear, suitable for industrial and mining enterprises with a three-phase single bus power transformer and power distribution system with an AC frequency of 50Hz and a rated voltage of 3-10KV. It is used to receive and distribute power, and realize the control, protection and detection of the circuit.

HXGN-12 indoor high voltage switch cabinet

1. Power transmission operation

When the cable compartment (front door) is closed and locked, the load switch cannot be closed. Operate the grounding switch to the open position and close the vacuum switch.

Operating procedure:

First close the cable room (front door) → sub-earth switch → close load switch

2. Power failure operation:

Press the trip button at the bottom right of the panel, the switch opens, the live display goes out, and the grounding switch is closed.

Operation sequence:

Open the vacuum switch → close the grounding switch.

Main feature:

Altitude does not exceed 1000m

Ambient temperature -25℃-+40℃;

Relative humidity: the daily average value is not more than 95%, and the monthly average value is not more than 90%;

Places without conductive dust, corrosive gas and water vapor:

There is no danger of fire and explosion;

There is no place with frequent severe vibration.

Environmental conditions for use:

The upper limit of ambient temperature is +40℃, and the lower limit is -25℃;

The altitude does not exceed 10000m;

The daily average value of air relative humidity is not more than 95%, and the monthly average value is not more than 90%; the daily average value of water vapor is not more than 2.2x 10-Mpa, and the monthly average value is not more than 1.8 x 10-Mpa:

The surrounding air is not significantly polluted by corrosive or combustible gas, water vapor, etc.;

No frequent severe vibration.

Order notice

1. Conventional products are carried out in accordance with the company's design standards, production standards, and inspection procedures. Users must understand the product attributes in detail;

2. If the drawings provided by the user can be quoted, produced and inspected according to the drawings;

3. Users without drawings must explain the product purpose, use occasions, motor power, working voltage, control mode and other parameters;

4. The product has undergone rigorous testing before leaving the factory and marked with various functional labels. If you have any questions, please call or email for consultation.
