GIS 24kv 50HZ SF6 Ring Main Unit
SF6 high-pressure gas-filled ring main unit uses SF6 gas as the arc extinguishing and insulating media. The switchgear is a fully sealed and fully insulated structure: the bus bars and switches are all enclosed in stainless steel shells. The cavity is filled with 1.4 bar of SF6 gas, and the protection level reaches IP67: the entire switch device is completely immune to external environmental conditions, and can ensure the normal operation of the switch even under extreme conditions such as short-term flooding. The product is maintenance-free for life. The switchgear has a reliable and safe pressure relief channel, which can guarantee the personal safety of the operator even under extreme conditions. The switchgear is divided into two types: fixed unit combination and expandable unit combination. The switch cabinet usually enters and exits from the front, and can also realize side exit or side expansion according to different installation positions. The switchgear size is easy to install, and can be suitable for places with small space and poor environmental conditions. The switchgear can be equipped with electric, remote control and monitoring devices to simulate the different needs of users.
Description
GIS 24kv 50HZ SF6 ring main unit
Environmentally friendly products
* 24kV 90%N2+10%SF6 C-GIS
* 40.5kV 50%N2+50%SF6 C-GIS
* 40.5kV 100%SF6 C-GIS
* 40.5kV 100%N2 C-GIS
-Vacuum Circuit Breaker,
-Three position disconnecting switch
-Enough height for cable entry.
Structural features:
GPRC2B power supply continuity level
Cabinet size:
1250A: 600×1600×2400mm
2500A: 800×1600×2400mm
SF6 gas insulation, vacuum breaking
Double gas box structure: busbar and circuit breaker are located in two gas boxes, with independent gas density meter
All high-pressure circuits are gas-sealed
German DIN standard inner cone in-line cable terminal
Cable height: ≥900mm
In case of a situation, there is no need to move the cabinets on both sides, the middle cabinet can be removed and replaced.
Technical parameter
PRODUCTION LINE
CERTIFICATE
EXHIBITION
COMPANY OVERVIEW
FAQ
Q5 : Is OEM/ODM available?
A: Yes, it is! Our products can be Customized. We have design and engineer teams,we can customize products according to customers' drawing or requirements.
Q6 : You are manufacturer or trading company?
A: We are factory, As a 100% professional manufacturer with 20 year's manufacturer experience, we could produce products according to customers' requirements and we could also control the quality of products 100%.
Q7 : Can the price be negotiated?
A: Yes, the price is negotiable. It can be changed according to your quantity or package
Q8 : How about inspection?
A: We have the whole inspection system from raw material to end products include temperature rise test,salt spraying test conductor type test,mechanical life test.
Q9 : What is payment terms?
A: T.T, Paypal,Western Union,Alibaba trade assurance and L/C is acceptable. 30% T/T in advance ,70% balance before shipment.
