The solid insulated metal-enclosed switchgear for ring network is a more environmentally friendly and reliable new generation ring network switchgear, which meets the requirements of replacing the traditional SF6 inflatable cabinet in the 10kV medium voltage power distribution system. And 1,250A or less. The main conductive components of the switchgear are packaged in a mature and reliable solid sealing process, and the incoming and outgoing wires are connected by cable connectors that meet European standards. The primary circuit has breaker break (or load switch break), isolation break and ground break. It can be operated in the correct program through the spring operating mechanism and mechanical interlock.

1. Application

Used in three-phase AC 50Hz, rated voltage 40.5kV power distribution system, as the receiving and distribution of electric energy. The double bus structure can be derived from products. Equipment that uses angle steel and bent steel plate to be welded together. Configurable types of ZN12-40.5 and ZN72-40.5, such as vacuum circuit breakers, are used for fixed installation of circuit breakers. The protection grade is IP2X, with reliable mechanical interlock function to prevent misoperation.

2. Environmental conditions

1) Ambient temperature: -10°C- +40°C;

2) Altitude: high pressure ≤1000Meter, low pressure ≤2500Meter (exceeding it will be specially designed by the technical department);

3) Relative humidity: ≤85%

4) Seismic strength: ≤8 level;

5) Suitable for places with no fire, no explosion hazard, no serious pollution, no chemical corrosion, and no severe vibration.

The intelligent compact solid insulation switchgear is developed and produced by our company with independent intellectual property rights. Based on the development requirements of the smart grid, the design concept adopted is "smart, energy saving, environmental protection and free maintenance". It integrates functions of measurement, control, protection, communication, etc., with a high degree of intelligence. It is the preferred equipment to ensure the safe, reliable, economical and efficient operation of the power grid.

Company Introduction

Henan Fengyuan Power Technology Co., Ltd., founded in 2010 with registered capital of 20 million yuan, a fixed asset of 50 million yuan, more than 200 employees and an annual output value of nearly 100 million yuan, located in Jiyuan City, Henan, China.

The main business for electrical appliances and complete sets of equipment and system integration, integrated automation controlsystem, such as sales, installation, technical services and domestic and foreign project contracting.Relying on the advanced R & Dability, innovative technology and manufacturing level of Fengyuan Power Technology, the company implements all-round operationmanagement, establishes product quality with professional quality, and creates value for customers.

Fengyuan focuses on producing KYN61-40.5 power distributing cabinet, KYN28-12, XGN15-12, HXGN15-12 and other model high,medium and low voltage switchgear equipment, movable transformer prefabricated substation, generator automatic controlling cabinet, dual power automatic switching device, draw-out low voltage switchgear GCK, GCS, MNS series, fixed low voltage switchgear GGD series, and other controlling, metering, switching box or cabinet series products.

Tips for quote &placing order:

The customer shall specify the following items:

Primary circuit scheme and single line system diagram

Secondary circuit schematic diagram, the wires shall be connected according to factory standard if customer has no requirement;

Switchgear arrangement diagram, plan view of electric power substation.

Detailed specification and parameter of electric element of each circuit;

Surface colour of switchgear;

Other requirements.
