Dry Type Amorphous Metal Core Transformer

Overview

Amorphous alloy is a new type of material with excellent magnetic properties. Due to the rapid cooling and solidification technology, the structure of the amorphous alloy is completely different from that of silicon steel. Because of the disordered arrangement of metal atoms, amorphous alloys are easier to be magnetized and demagnetized. The no-load loss of dry-type amorphous metal core transformers is 75% lower than the value specified in the GB/T10228 standard, and the no-load loss is reduced by 15%.

The product is characterized by low no-load loss, no oil, flame retardancy, moisture resistance, crack resistance and maintenance-free. It can be used to replace ordinary dry-type transformers in high-rise buildings, business centers, subways, airports, stations, industrial and mining enterprises, power plants and other places. It is especially suitable for use in flammable and explosive places.

Our SCBH10 dry-type amorphous metal core transformer meets the following standards: GB1094.11-2007 "Dry Type Power Transformer", GB/T10228-2008" Technical Parameters and Requirements of Dry-Type Power Transformers", GB1094.1-2-1996 "Power Transformer", and GB1904.5-2003 "Power Transformer".

Service and installation conditions

Maximum temperature: + 40°C

Maximum monthly average temperature + 30°C

Average annual maximum temperature: + 20°C

Minimum temperature: -5°C

Power supply voltage waveform: approximate sine wave

No obvious pollution in the installation environment

For indoor use transformer

Structural features

The low-voltage coil of this product is wound with copper foil, and the high-voltage coil is wound with H-class high-strength enameled wire. The epoxy resin structure is reinforced by glass fiber, which has excellent crack resistance and moisture resistance. The iron core is rolled from an amorphous alloy strip. The structure is rectangular section, four frames and five columns or three frames and three columns.

three phase dry type electric transformer

1.Safe, fireproof, no pollution, it can be installed directly in the load center.
2.Free maintenance, easy to install, low total operating costs.
3.With good moisture resistance, it can work normally under the100% humidity. After it stopped operating, the outage without pre-drying can be put into operation again.
4.Low loss, low partial discharge, low noise, good heat dissipation capacity. Under the forced air cooling conditions, it can run at 150% rated load.
5.The equipped perfect humidity protection & control system can provide reliable

Function Characteristics:

1. Flame retardant, non-pollution, it can be installed directly in the load center.
2.Maintenance-free, easy to be installed, low operating costs.
3.The enclosure can be of Good moisture resistance, transformer can be put into operation without pre-drying under 100% humidity in the normal operation.
4.Low loss, light weight and small volume, low noise, good dissipation of heat, it can be 150% rated load operation under forced air cooling conditions.
5.Equipped with a complete temperature protection control system to provide reliable protection for the safe operation of
transformers.
6.High reliability. The results of checking for the products that has been put into operation show that the reliability index has reached the international advanced level.

Structural Characteristics:

Cast-foil Coil: Adopting the entire section of copper foil, together with the F-class turn insulation, low voltage winding is wound by the special low-voltage foil winding machine. The foil coil resolves such understanding problems as large short-circuit stress, uneven ampere turn, poor heat dissipation, existing the winding spiral angle as well as unsteady manual welding quality due to low voltage and large current coil winding products. At the same time, the winding end in our company is treated with resin potting, solidification to make shape, moisture-proof and anti-fouling, the lead copper platoon is automatically welded by argon arc welding.

Temperature Control Device: the transformer adopts BWDK series of signal thermometer. The temperature components, are embedded in the upper half of the low-voltage coil, can automatically detect and dynamically display the work humidity of phase coils and also have the functions of over-temperature alarm and trip.

PRODUCT PHOTO

FACTORY

CERTIFICATE

EXHIBITION

COMPANY OVERVIEW

Henan Fengyuan Power Technology Co., Ltd. was established in July,2010, mainly producing high voltage switchgear including box-type transformer substation and low voltage switchgear including various types of distribution boards, which are widely used in power transmission and distribution systems such as power, transportation, mining, metallurgy, construction, petrochemical, communication and urban power network construction and transformation.

We have gradually established quality management system and we obtained ISO9001,ISO14001 and OHSAS18001.The high voltage products have passed the test of national standard,and low voltage products have gained national CCC certificates.

Packaging & Shipping

FAQ

Q5 : Is OEM/ODM available?

A: Yes, it is! Our products can be Customized. We have design and engineer teams,we can customize products according to customers' drawing or requirements.

Q6 : You are manufacturer or trading company?
A: We are factory, As a 100% professional manufacturer with 20 year's manufacturer experience, we could produce products according to customers' requirements and we could also control the quality of products 100%.

Q7 : Can the price be negotiated?

A: Yes, the price is negotiable. It can be changed according to your quantity or package

Q8 : How about inspection?

A: We have the whole inspection system from raw material to end products include temperature rise test,salt spraying test conductor type test,mechanical life test.

Q9 : What is payment terms?

A: T.T, Paypal,Western Union,Alibaba trade assurance and L/C is acceptable. 30% T/T in advance ,70% balance before shipment.
